MIL-C-16645A(SHIPS)
3.6.4.2 When the contract or order specifies non-magnetic equipment, all special tools shall be of
non-magnetic material (see 3.4. 4).
3.6.4.3 Tools which are available in the Catalog of Naval Material, General Stores Section, such
as common wrenches and standard pullers, will not be required. Standard complete or limited sets of
pullers or parts of puller sets in accordance with Specification GGG-P-781 shall be identified as to type
and use in notes on the outline or section assembly drawings. Special tools (special tools are defined as
those tools not listed in the Catalog of Naval Material, General Stores Section (copies of this catalog may
be consulted in the office of the Government inspector)) shall be detailed, and included in the list of
material.
3.6.4.4 Each box containing onboard repair parts shall contain a list entitled "List of onboard
repair parts anti tools", The list shall be in format suitable for use on outline drawings and in the
instruction books. It shall not be less than nominal 8-1/2 by 11 inches in size.
3.6.4.4.1 The format of the list shall include a heading and columns of data for the items listed.
The heading shall include titles and applicable entries as follows:
Reproduced from drawing number
Number of ships
Application
Contract number
Manufacturer
units per ship
Quantities are for
The columns shall include:
Piece number
Name of part
Quantity
Drawing number
Standard Navy stock number
Additional columns may be used as applicable
3.6.4.4.2 The list shall be so treated as to be resistant to oil, water and fading.
3.6.5 Stock.- The selection, stock numbering and quantities of repair parts for stock shall be
determined and processed in accordance with Specification MIL-R-15137.
3.6, 5.1 The cognizant supply demand control point for repair parts for stock is Ships Parts Control
Center, Mechanicsburg, Pennsylvania, unless otherwise specified in the contract or order.
3.7 Drawings.-
3.7.1 Drawings shall be in accordance with type I of Specification MIL-D-963.
3.7.2 Outline drawings shall be furnished covering complete units including compressor, driver,
bedplate and attached accessories. The center of gravity of complete units shall be indicated on each
outline drawing. Separate outline drawings shall be furnished for each contract or order and for each
different unit on a contract or order.
.
3. 7.3 Compressor master drawings shall include sectional assembly, complete list of material and
details of all parts. The sectional assembly and list of material with references to detail drawings
should be on a single sheet; and details shall be on one or more additional sheets. Several details should
be shown on each master drawing, Details of single parts on size A sheets, resulting in a multiplicity of
drawing sheets, should be avoided. Size F drawings (28 by 40 inches) are preferred.
