MIL-C-0052980C(ME)
Each end item, or independent
3.14.1 Shipping data Plate.
component assemblage thereof, shall have a shipping data plate
The shipping
attached as near as practicable to the name plate.
data plate shall conform to MIL-P-514, type III, composition C, of
type I, grade A, class 1 material and in addition, shall show the
silhouette of the compressor in transport position indicating the
center of gravity, the location and capacity of the lifting and the
The plate shall be attached by screws, bolts,
tiedown attachments.
or rivets marked with the following information:
Length - inches.
Height - inches.
Width - inches.
Cube - cubic feet.
Gross vehicle weight - pounds.
Center of gravity - location, inches.
The gross weight and location of the center
3.14.2 Stenciling
of gravity on each end item shall be stenciled on each unit in a
manner easily discernible to personnel handling the equipment.
Each compressor shall be equipped with
3.15 Instruction Plates.
instruction plates or diagrams, including warnings and cautions,
describing any special or important procedures to be followed in
Instruction
assembling, operating or servicing the compressor.
plates shall conform to MIL-P-514, type III, composition C, of
type I, grade A, class 1 material.
Plates shall be attached by
screws, bolts or rivets in a conspicuous protected location.
The compressor, components, and
3.16 Treatment and painting.
parts painted in commercial practice shall be cleaned, treated and
painted in accordance with MIL-T-704, type F or G, as applicable.
Unless otherwise specified (see 6.2), top coat color shall be
When specified (see
camouflage green 383 conforming to MIL-C-46168.
6.2), the compressor shall be overcoated in accordance with the
Government furnished camouflage patterns with MIL-C-46168 top coat
of the colors specified in the camouflage patterns except the first
Components which reach
article may be camouflage green 383.
temperatures of 450 °F or more shall not be overcoated with
MIL-C-46168 top coat.
When specified (see 6.2 and
3.16.1
Camouflage Pattern data.
6.3), the contractor shall be provided camouflage pattern data.
When specified (see 6.2 and
3.17 Go ver nment- furnished Property.
6.6), the following property in the quantities indicated will be
furnished by the Government for the applicable size compressor (see
6.6):
10
