MIL-C-0052980C(ME)
Compress
Quantity for
Item
Description
Item
Identification
each
or Size
Number
compressor
5 cfm
1
Military design
Model 1A08
1
l-1/2-hp
gasoline engine
15 cfm
1
Model 4A032
2
Military design
6-hp gasoline
engine
3
15 cfm
Starter and 6-hp
NSN
1
gasoline engine
2940-00-882-3401
As required
Camouflage
paint
pattern
3.18 Government-loaned property
When specified (see 6.2 and
6.7), Government-loaned property, the following property in the
quantity indicated will be loaned by the Government (see 6.7).
Description
Identification
Quantity
Heater, engine
NSN
1 each
and shelter,
4520-00-203-0224
ground Type H-1
3.19
Type I, reciprocating.
3.19.1 Compressor.
The type I compressor shall deliver the
capacities of free air (see 6.8) specified in table I at a pressure
of 175 pounds per square inch gauge, (psig) as determined by ASME
Performance Test Code 9.
The components of the compressor shall be
balanced so that when the compressor is operated in conjunction with
the gasoline engine, vibration shall be minimized.
The compressor
s
shall not exceed the contractor recommended continuous operating
speed.
The compressor shall be air cooled.
The cylinder heads or
cylinder assembly (if cast integral) shall be removable.
The intake
and exhaust valves shall be removable.
A fan shall be provided for
cooling.
TABLE I.
Compressor
characteristics.
Rated discharge
Size (cfm)
Minimum capacity Maximum
pressure (psig)
(free air) (cfm) operating
pressure (psig)
5
5
200
175
175
15
200
15
175
25
200
25
11
